Ezviz H7c Dual

Price:

$
52.00

Product Detail

Ezviz H7c Dual

Camera
Resolution Dual 2K+ Resolution
Image Sensor 1/3" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Fixed Lens 2.8mm@F1.6 , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
PT Lens 6mm@F1.6 , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
Compression
Video Compression H.264/H.265
Video Bit Rate Adaptive bit rate.
Network
Smart Alarm Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
Wi-Fi Pairing AP paring
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Max. Resolution 2560 × 1440
Frame Rate Max:30fps; Self-Adaptive during network transmission
Interface
Storage Micro SD card slot (Max. 512G)
Power TYPE-C
Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
Frequency Range 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz
Channel Bandwidth 2.4GHz Supports 20MHz 5GHz Supports 80MHz
Security WPA-PSK, WPA2-PSK, WPA3-Personal
Transmission Rate 2.4GHz Max. Rate Support: 11b_11M，11g_54M, 11n_MCS7_20M，11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M，11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M
Output Power(EIRP) 20 dBm
Antenna Gain 2.56dBi@2.48GHz，3.18dBi@5.22GHz
General
Operating Conditions -10°C to 45°C ( -14 °F to 113 °F ) Humidity 95% or less (non-condensing)
Power Consumption 8W max
Power Supply DC 5V/2A
IR Range MAX. 10 meters (32.81ft)
Dimensions 88 × 88 × 131.5 mm (3.46 × 3.47 ×4.69 in)
Package Dimensions 200 ×105 ×105 mm (7.87 × 4.13 × 4.13 in)
Net Weight 270 g (9.52 oz)
Bare Weight 499 g (17.60 oz)
In the box
In the box - Camera (x1)
- Power Adapter (x1)
- Power Cable (x1)
- Drill Template (x1)
- Mounting Plate (x1)
- Screw Kit (x1)
- Regulatory Information (x1)
- Quick Start Guide (x1)


Brand & Category: Ezviz, WiFi Camera
